Panoramica
Quando vuoi passare da più set di monitor e più sorgenti analogiche e digitali e ascoltare esattamente come suona il tuo mix, senza colorazione, hai bisogno del controller per monitor professionale PreSonus® Central Station PLUS. Il suo percorso del segnale passivo di qualità audiofila, senza amplificatori operazionali o circuiti integrati, e i suoi ingressi S/PDIF con convertitori D/A a 24 bit e 192 kHz assicurano la trasparenza sonora di cui hanno bisogno i professionisti.
Facile passaggio tra tre set di sorgenti di ingresso analogiche stereo e una sorgente di ingresso digitale stereo e ascoltale con un massimo di tre coppie di altoparlanti, con trim pot individuali per ogni altoparlante. Ottieni anche due amplificatori per cuffie urlanti con controlli di livello individuali. Se ciò non bastasse, collega le uscite Cue a livello di linea a un sistema di distribuzione delle cuffie, come un PreSonus HP2, HP4 o HP60.
Abbiamo incluso molti extra. Parla con i musicisti tramite le cuffie e i cue bus utilizzando il microfono talkback integrato o collega un microfono dinamico all'ingresso XLR Talkback. Un ingresso per interruttore a pedale consente il funzionamento del talkback a mani libere. Un interruttore Mono somma la sorgente stereo per verificare la presenza di problemi di fase e gli interruttori Dim e Mute consentono di ridurre o silenziare le uscite degli altoparlanti senza modificare la manopola del livello principale. Il telecomando CSR-1 incluso ti consente di gestire tutto dal tuo desktop.
Con il suo I/O, la qualità audio e le funzionalità, non sorprende che la Central Station PLUS con montaggio su rack 1U sia la scelta dei professionisti per il controllo del monitor.
Overview
Caratteristiche
- Passive audio path - no op amps or ICs - for minimal noise and coloration
- Manage 3 stereo analog sources and 1 digital source, using 2 stereo pairs of balanced ¼-inch line-level inputs, 1 stereo pair of unbalanced RCA line-level inputs and 2 S/PDIF digital inputs (coax and optical, 24-bit/192 kHz)
- Switch between 3 sets of monitor speakers using 3 stereo pairs of balanced ¼-inch, line-level speaker outputs with
- Speaker Select switches and recessed trim pot for each output
- Main section with with 2 (L/R) balanced ¼-inch, line-level outputs with Input-select switch, Aux-input level control, Output-level control and Mute, Dim (-20 dB) and Mono switches
- Cue section with 2 (L/R) balanced ¼-inch, line-level outputs, Input-select switch and Output-level control
- 2 loud stereo ¼-inch headphone outputs with dual-function volume controls and Main/Cue input switches
- Onboard electret condenser talkback microphone, balanced XLR Talkback microphone input w/level control (feeds Headphone and Cue outputs) and footswitch jack for hands-free talkback operation
- Dual 30-segment, fast-acting, peak-hold LED metering (dBu and dBfs) with Clear Peak switch and calibration to match DAW or other audio device
- Included Central Station Remote (CSR-1) wired remote control
- 1U 19-inch rack-mountable, rugged steel chassis and external AC power supply
Download
Non trovi quello che stai cercando?
Accedi al tuo account my.presonus.com.
Documentation
Non trovi quello che stai cercando?
Accedi al tuo account my.presonus.com.
In primo piano
Ingressi digitali ad alta definizione
Gli ingressi digitali S/PDIF coassiali e ottici della Central Station PLUS forniscono una conversione da digitale ad analogico fino a 24 bit, 192 kHz, con oltre 115 dB di gamma dinamica. La stazione centrale rileverà automaticamente e si aggancerà alla frequenza di campionamento del dispositivo sorgente.
Componenti passivi per audio trasparente
La stazione centrale PLUS non utilizza amplificatori operazionali o circuiti integrati, solo componenti passivi di alta qualità, inclusi resistori a film metallico di grado militare con tolleranza dell'1%; potenziometri multielemento; e connettori durevoli. Il risultato è un percorso del segnale trasparente; massima gamma dinamica, risposta in frequenza e headroom; e minimo rumore e colorazione.
Telecomando cablato CSR-1
Il telecomando cablato Central Station Remote (CSR-1) incluso si collega tramite un cavo DB15 e consente di gestire Main Volume, Input Select, Output Select, Talkback, Mute, Dim e Mono summing — tutto dal tuo desktop. Installa in rack la Central Station PLUS 1U e usa il CSR-1 per il massimo controllo e flessibilità.
Specifiche
Accessories
Footswitch
Optional 1-Button Footswitch for Talkback
Elettroniche
VoltageRequirements
100-240 VAC, 50-60 Hz
Generale
Color
Silver
Product Name
Central Station PLUS Monitoring Controller, Silver, 220-240V UK
Series
Monitoring Controllers
Hardware
Microphone Types
Internal Electret Condenser
SPDIF Connection Type
RCA 75Ω Coax and Toslink Optical
Speaker Output Connection Type
1/4" TRS, Balanced
Ingressi
Auxiliary Input Connection Type
RCA Active, Unbalanced
Auxiliary Input Frequency Response
10 Hz-50 kHz (-0.5 dB)
Auxiliary Input Gain Range
-90 dB to +20 dB
Auxiliary Input Impedance
8 kΩ
Auxiliary Input Signal To Noise Ratio
> 115 dB (1 kHz @ 0 dBu, Unity Gain)
Auxiliary Input Total Harmonic Distortion
< 0.002% (1 kHz @ 0 dBu, Unity Gain)
Line Input Connection Type
1/4" TRS, Balanced
Line Inputs Frequency Response
> 1 MHz
Line Inputs Impedance
2-5 kΩ (Speaker Load and Trim Level Dependent)
Line Inputs Signal To Noise Ratio
> 140 dB
Line Inputs Total Harmonic Distortion
< 0.0005% (1 kHz @ 0 dBu)
Microphone Input Connection Type
XLR Female, Balanced
Microphone Preamp Gain Control Range
15 to 55 dB
Microphone Preamp Input Impedance
2,400Ω
Measurements
Product Depth
6.25" (15.9 cm)
Product Height
1.75" (44.45 mm)
Product Width
19" (48.3 cm)
Varie
Commodity Code
8518400090
Power Cable
External A.C. Transformer/Internal Linear
Output
Cue Output Connection Type
1/4" TRS Active-Impedance Balanced
Cue Output Dim Attenuation
-30 dB (Talkback Activated)
Cue Output Frequency Response
10 Hz-50 kHz (-0.5 dB)
Cue Output Gain Range
-90 dB to 0 dB
Cue Output Impedance
51 ohms
Cue Output Total Harmonic Distortion
Less than 0.003% (1 kHz @ 0 dBu)
Headphone Outputs Frequency Response
10 Hz-50 kHz (+1 dB)
Headphone Outputs Maximum Output
150 mW/Channel @ 60Ω Load
Headphone Outputs Total Harmonic Distortion
0.015% (150 mW/Channel @ 60Ω Load)
Main And Line Outputs Frequency Response
10 Hz-50 kHz (-0.5 dB)
Main And Line Outputs Output Impedance
51Ω
Main And Line Outputs Total Harmonic Distortion
< 0.0025%
Main Outputs Connection Type
1/4" TRS, Balanced
SPDIF Maximum Output
+18 dBu (Active-Balanced)
SPDIF Total Harmonic Distortion
0.0025% (1 kHz @ -1 dBfs)
Prestazione
Microphone Sensitivity
-42 dB
SPDIF Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz
Altoparlanti
Speaker Output Dim Attenuation
-30 dB
Speaker Output Main Level Range
-90 dB to 0 dB
Speaker Output Trim Range
-90 dB to 0 dB
Specifiche
Accessories
Footswitch
Optional 1-Button Footswitch for Talkback
Elettroniche
VoltageRequirements
100-240 VAC, 50-60 Hz
Generale
Color
Silver
Product Name
Central Station PLUS Monitoring Controller, Silver, 220-240V EU
Series
Monitoring Controllers
Hardware
Microphone Types
Internal Electret Condenser
SPDIF Connection Type
RCA 75Ω Coax and Toslink Optical
Speaker Output Connection Type
1/4" TRS, Balanced
Ingressi
Auxiliary Input Connection Type
RCA Active, Unbalanced
Auxiliary Input Frequency Response
10 Hz-50 kHz (-0.5 dB)
Auxiliary Input Gain Range
-90 dB to +20 dB
Auxiliary Input Impedance
8 kΩ
Auxiliary Input Signal To Noise Ratio
> 115 dB (1 kHz @ 0 dBu, Unity Gain)
Auxiliary Input Total Harmonic Distortion
< 0.002% (1 kHz @ 0 dBu, Unity Gain)
Line Input Connection Type
1/4" TRS, Balanced
Line Inputs Frequency Response
> 1 MHz
Line Inputs Impedance
2-5 kΩ (Speaker Load and Trim Level Dependent)
Line Inputs Signal To Noise Ratio
> 140 dB
Line Inputs Total Harmonic Distortion
< 0.0005% (1 kHz @ 0 dBu)
Microphone Input Connection Type
XLR Female, Balanced
Microphone Preamp Gain Control Range
15 to 55 dB
Microphone Preamp Input Impedance
2,400Ω
Measurements
Product Depth
6.25" (15.9 cm)
Product Height
1.75" (44.45 mm)
Product Width
19" (48.3 cm)
Varie
Commodity Code
8518400090
Power Cable
External A.C. Transformer/Internal Linear
Output
Cue Output Connection Type
1/4" TRS Active-Impedance Balanced
Cue Output Dim Attenuation
-30 dB (Talkback Activated)
Cue Output Frequency Response
10 Hz-50 kHz (-0.5 dB)
Cue Output Gain Range
-90 dB to 0 dB
Cue Output Impedance
51 ohms
Cue Output Total Harmonic Distortion
Less than 0.003% (1 kHz @ 0 dBu)
Headphone Outputs Frequency Response
10 Hz-50 kHz (+1 dB)
Headphone Outputs Maximum Output
150 mW/Channel @ 60Ω Load
Headphone Outputs Total Harmonic Distortion
0.015% (150 mW/Channel @ 60Ω Load)
Main And Line Outputs Frequency Response
10 Hz-50 kHz (-0.5 dB)
Main And Line Outputs Output Impedance
51Ω
Main And Line Outputs Total Harmonic Distortion
< 0.0025%
Main Outputs Connection Type
1/4" TRS, Balanced
SPDIF Maximum Output
+18 dBu (Active-Balanced)
SPDIF Total Harmonic Distortion
0.0025% (1 kHz @ -1 dBfs)
Prestazione
Microphone Sensitivity
-42 dB
SPDIF Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz
Altoparlanti
Speaker Output Dim Attenuation
-30 dB
Speaker Output Main Level Range
-90 dB to 0 dB
Speaker Output Trim Range
-90 dB to 0 dB
